Model Name

SH01

CPU

Intel® i5-6500, Supoort intel 6,7 and 8 Generation

Memory

1 x SO-DIMM slot ,support DDR3L

1333/1600MHz , Maximum support 8Gb

Storage

1x SATA 7Pin 3.0 (6Gb/s) Connector;

1x Full size Msata

Expansion Slot

2 x Mini PCIE Connector (Full size mSATA;

Half size WLAN/Bluetooth); 1 x SATA 7Pin 3.0

(6Gb/s) Connector

Rear I/O

4 x USB 2.0;

2 x USB3.0,

2 x RJ45 10/100/1000Mbps LAN  1xHDMI;

1xVGA,

1xDP

1x PS2

1x DC IN 19V

Internal I/0

1 x mSATA

2 x USB 2.0

1 x Wifi

2 x SATA

1 x Audio

6 x SIO port

1x LPT

OS

Windows 10 / 7 / Linux

Dimensions (mm)

170 x 170
