CPU

Intel®   C3558R，2.4GHz，TDP17W

DDR

2666/2400 /2133 MHz UDIMM/RECC DDR4   8GB、16GB、32GB、64GB\256GB

DIMM

4 × RDIMM， DDR4

Storage

2 × M.2 ，support NVME SSD

14 × SATA3

Network

2-Port 10 Gigabit Network，SFP+，MAC in cpu

IO

2 × USB3.0

2 × SFP+

1 × COM，RJ45

1 × IPMI，RJ45

2 x LAN State LED，1 x Power LED，1 x BMC LED

chip

Hi3518E

Management port

1 × RJ45，10/100Base-T

Software

1、Read the chassis power supply, fan, temperature information, node information, and locate the node location；

2、Remote switch；

3、Serial Over LAN (SOL) ，

4、Support ipmi2 0 agreement；

Size

770mmX 447mmX 198mm, 25kg

Power in

AC100-240V 60-50Hz，80PLUS Gold/Platinum，1300W（1+1）Redundancy powe

Temperature

working temperature: 0° to 40°C ；

Deposit temperature: -40° to 70°C

RH

Working RH: 8% to 90%；

Deposit RH: 5%   to   95%
