CPU

Intel® Xeon® processor E5-2600 v4†/ v3 family;

UPI up to 9.6GT/s

Chipset

Intel® C612 chipset

DDR

512GB Registered ECC RDIMM, DDR4-2400MHz

Up to 1TB 3DS ECC LRDIMM, in 8 DIMM slots

DIMM

RDIMM: 4GB, 8GB, 16GB, 32GB, 64GB

LRDIMM: 32GB, 64GB

3DS LRDIMM: 128GB

Storage

1 × M.2

10 × SATA3 (6Gbps) ports

Network

2-Port 1000Base-T，RJ45

Intel I210AT

IO

2 x USB2.0 ports

4 × USB3.0

2 × RJ45（10/100/1000Base-T）

1 × RS-232,DB9

1 × PCIE-E3.0 X 16（×16 Lane）

1 × VGA

BMC

ASPEED AST2400 BMC

Remote management

1 x RTL8211E PHY

Software

IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Size

490mm× 440mm× 88.9mm

Weight

15KG

Power

550W 1+1Redundancy powe

Power in

AC100-240V 60-50Hz，80PLUS Titanium Leve

Temperature

working temperature: 0°to 45°C

Deposit temperature: -40°to 70°C

RH

Working RH: 8% to 90%(non-condensing）

Deposit RH:5%   to   95%(non-condensing）
