CPU

Intel®   Ice Lake-SP

Chipset

Intel® C621A Chipset (LBG-R)

DDR

32*DDR4, RDIMM/LRDIMM,support 3200MT/S

Support intel BPS DDR

3200/2933/2666/2400MHz ECC DDR4 SDRAM 72-bit

DIMM

RDIMM：128GB，64GB, 32GB, 16GB, 8GB；LRDIMM：64GB, 32GB

HDD

12*3.5(8 SATA+4NVMe)

4* 2.5 (SATA/NVMe) 2: 2*3.5 (SATA)

Network

2-Port   1000Base-T，RJ45

1*OCP3.0(Upto 200G)

IO

2 × VGA

4 × USB 3.0 ports

1 × USB 2.0 ports，Type A

8* PCIe AIC (with up to 4* FHFL or 2* DW GPU)

1 × Console over RJ45

1 ×UID button

BMC

ASPEED AST2500

Remote management

1 × RJ45，100/1000Base-T

Software

The management network interface supports intelligent management interface v2 0, support IPMI 2.0 of virtual media on LAN and LAN of KVM

Size

786mmx   447mm× 88mm

Weight

20kg

Power

1600W 1+1 Redundancy powe

Power in

AC100-240V 60-50Hz，80PLUS Titanium Leve

Temperature

working temperature: 0°to 45°C

Deposit temperature: -40°to 70°C

RH

Working RH: 8% to 90%(non-condensing）

Deposit RH:5%   to   95%(non-condensing）
