Model Name

KU-02

CPU

Core™   i7-7500U (Kaby Lake-R，Kaby Lake-U）

Memory

1 x SO-DIMM slot

DDR4   2133Hz, Maximum support 16GB

Storage

1 x SATA 7Pin 3.0 (6Gb/s) Connector;

Full size Msata

Expansion Slot

1 x PCIE Connector (Full size mSATA;

Half size WLAN/Bluetooth);

1 x Msata Connector

3 x Mini PCIe for VPU/others

1 x PCIe 4 for Graphics card/others

1 x Mini pcie for 3G/4G card

1x SIM card slot

Front I/O

2 x USB 3.0;

2 x RJ45   1000Mbps LAN

1x Audio in / 1x Audio out

1 x HDD Led 1 x Power button

Rear I/0

2x RJ45 10/100/1000Mbps Lan 1x HDMI;

1 x DP

1 x VGA,

2x USB 3.0,

2x USB 2.0

6 x SIO 1 x 12V DC Jack

OS

Windows 10

Power supply

AC Adapter 19V/5A DC

Dimensions (mm)

310 x 180 x 68 （Board size 170 x 170)
