Model Name

CJ-02

CPU

Intel® Celeron® Processor J1900/J1800 2M

Cache, up to 2.42/2.58 GHz, Quad Core; 10W

Memory

1 x SO-DIMM slot ,support DDR3L

1333/1600MHz , Maximum support 8GB

Storage

1 x SATA 7Pin 3.0 (6Gb/s) Connector;

Full size Msata

Expansion Slot

2 x Mini PCIE Connector (Full size mSATA;

Half size WLAN/Bluetooth); 1 x SATA 7Pin 3.0

(6Gb/s) Connector

Front I/O

3 x USB 2.0;

1 x USB3.0,

1 x MIC,

1 x Power Led 1 x Power button

Rear I/0

1 x RJ45 10/100/1000Mbps Lan （2*RJ45） 1xHDMI;

1xVGA,

1xF_Audio 1 x 12V DC Jack

OS

Windows 10 / 8 / 7 / Linux

Power supply

AC Adapter 12V/3A 36W DC

Dimensions (mm)

120 x 120 x 40
