CPU

Intel®9th/8th-GenCoffee lake Core™i7/i5 LGA1151

chipset

Intel® Q370

DDR

4*SODIMM, DDR4 2666/2400MHz, 128GB max

IO

1*full size Mini PCIe   support   PCIe+USB，Optional mSATA+SIM，support 4G、Wifi/BT1*M.2 E-Key 2230,

1* M.2 3052 B-Key +SIM，support 5G1*PCIe X16 support 150W（＜210mm）1*PCIe X4 (in X16 ), gen3.0 support 75W AI card（＜230mm）

GPU

Display

Intel UHD Graphics, Supports DirectX11.1, OpenGL 5.0 and OpenCL 2.1 or PCIe X16，DP 4096*2304@60Hz, VGA 1900*1200@60Hz，

Audio

Realtek ALC662VD   Audio out and MIC

Network

2*Intel I210AT PCIe Gig. Ethernet; 10/100/1000Mbps；1*Intel I219LM PCIe Gig. Ethernet, support iAMT12.0

Storage

2*2.5”SATA3 support Raid 0/1, 6G bit/s ；1*M.2 2280 M-Key，PCIex4Gen3.0, supp NVME

DIO

16 bit DIO, 8bit 2.5KV Optical isolation output   (H:5-24V, L:0-1.5V), 8 bit 2.5KV Optical isolation output (200mA)

I-Port

Support USB2.0、 16 bit DIO, or Mini PCIe and M.2

I/O

3*RJ45 Gig-LAN; 6*USB3.1 gen2.0 TYPE A，support 10G bit/s; 2*USB2.016 bit DIO2*RS232/422/485 ，option 2*RS2321*Audio-out   1*MIC1*VGA+2*DP

Led

1*power Led, 1*HDD Led,   3*CPU   temperature   Led

Button

1*Power SW，1*Remote switch，1*AT/ATX SW, 1*Clear CMOS SW

Power

DC IN 9-36V 3-pin Term.7.62mm，

TCM/TPM

Option support

watchdog

Support 1~225s

OS

Windows* 10 Enterprise & IOT Enterprise（64 位）(CFL-R)Ubuntu*、SuSe*、Redhat Enterprise* 1,2 (Kernel 4.14) (CFL-R)Wind River* VxWorks* 7 (CFL-R)
