Type

Items

Description

PC

CPU

Intel®J1900 2.0GHz Quad Core CPU

Chipsets

Base on Intel® Baytrail

Cache

2M L2 Cache

Ram

Support 1600/1333MHz DDR3L/1.35V Ram，Max 8GB

SSD

1x Msata

HDD

1x SATA 2.5”

LAN

1*RTL8111EGigabit Ethernet,

Support network wake-up /pxe function

I/O

1x Serial Port：RS-232 x 1;

1x VGA Port

Line out /MIC in

HDMI x1, USB 2.0 x3, USB3.0 x1

Bus extension

1 x Msata Slot

1 x MINI PCIe Slot

Front panel protection

Meet Standard:IP65/NEMA 4

Weight

1.9kg

Size(W x H x D)

211 x 193 x 49 mm

Software

MicrosoftWindows 7，10，Linux

Power Supply

12 VDC

LCD

Type

8" ColourTFT LCD

Resolution

1024 x 768

Maximum color /Grayscale

262 K

Pixel spacing(mm)

0.240 x 0.240

viewing angle

160°/160°

brightness(cd/m2)

300

Brightness support

Yes (Through BIOS)

LCD MTBF

50,000 hrs

Touch Panel Option

Type

Resistive /Capacitive

Resolution

Continuity

Light conduction

80%

Controller

USB Port

Durability

(number of touches)

35 million

Using Condition

Working Temp

0-60° C ;

Relative humidity

10~ 95 % @ 40°C, Non-condensing

Impact

10GPeak acceleration（11Milliseconds, interval）

Vibration

1 G

EMC

CE, FCC Class B, BSMI
