Type

Items

Description

PC

CPU

Intel® LGA 1150/1151 Core I3,I5,I7 whole series

Chipsets

Intel H81/H110

Cache

Depends on CPU

Ram

2x DDR4 Ram，Max 32GB

SSD

1x Msata

HDD

1x SATA 2.5”

LAN

4* RTL8111E Gigabit Ethernet,

Support network wake-up /pxe function

I/O

3x Serial Port：RS-232 x 3;

1x VGA Port

Line out /MIC in

HDMI x1, USB 2.0 x4, USB3.0 x4

PS2 x1

Bus extension

1 x Msata Slot

1 x MINI PCIe Slot

1x PS2

Front panel protection

Meet Standard: IP65/NEMA 4

Weight

10kg

Size(W x H x D)

408 x 340 x 107 mm

Software

Windows 7，10

Power Supply

12V, DC in

LCD

Type

17" ColourTFT LCD

Resolution

1280 x 1024

Maximum color /Grayscale

262 K

Pixel spacing(mm)

0.240 x 0.240

viewing angle

160°/160°

brightness(cd/m2)

350

Brightness support

Yes (Through BIOS)

LCD MTBF

50,000 hrs

Touch Panel Option

Type

Resistive

Resolution

Continuity

Light conduction

80%

Controller

USB Port

Durability

(number of touches)

35 million

Using Condition

Working Temp

0-60° C ;

Relative humidity

10~ 95 % @ 40°C, Non-condensing

Impact

10GPeak acceleration（11Milliseconds, interval）

Vibration

1 G

EMC

CE, FCC
