Size

160（L）*135（W）*50mm（H）

145 *100 *18mm

CPU

Intel® CPU: Celeron J1800、J1900、Pentium J2900

Chipsets

Intel Bay trail SOC Chipsets

Power

1*DC_JACK

DC head Internal diameter is 2.5mm，Support 12V

The full load power consumption of the main board is about 25W,
and 12v4a or above power supply is recommended

Ram

1*NB-DDR3L，Low voltage 1.35v memory, supporting 1333/1600mhz memory，Max support 8G

Graphic

Intel(R) HD Graphics Graphic controller,
supporting single display, double display replication, double display expansion, and single display under DOS

1*VGA DB15 Port

Resolution: 1920*1080@60HZ

1*HDMI 1.4 Port

Resolution: 1920*1080@60HZ

Ethernet

1*RJ45 LAN

RTL8111H Gigabit network card chip, supporting network wake-up and PXE diskless boot functions.

1*Mini-PCIE Port

Support WIFI/3G/4G/Bluetooth etc.

Storage

1*SATA1 Port

Standard SATA2.0 Connector，Max speed 3.0 Gbps

1*SATA-PWR Pin

The power supply pin of hard disk can be 5V or 12V（4Pin，1*4Pin，2.54mm）

1*MSATA Port

Support Standard MSATA 2.0

Audio

Integrated Realtek ALC662/660/892 HD Digital audio decoder, 6-channel high fidelity audio controller

1*LINE_OUT Port

Support audio output

1*JAMP Pin

The power amplifier supports 8 Ω 5 Watt horn dual channel output（4Pin，1*4Pin，2.0mm）

USB

1*USB3.0 Port

Standrd USB3.0 Port

7*USB2.0 Port

Standard USB2.0 Port

Switch

1*Power

Switch button

I/O

1*COM1 Port

Serial Port，Support RS232/RS422/RS485 as Options

1*COM2 Port

Serial Port，Support standard RS232

1*JPCOM1 Pin

Control the voltage of the 9th pin of COM1, 0V/5V/12V as option（6Pin，2*3Pin，2.0mm）

1*JPCOM2 Pin

Control the voltage of the 9th pin of com2, 0V/5V/12V as option（6Pin，2*3Pin，2.0mm）

1*SIM Card Slot

Support SIM Card，for matching with 3G/4G Module

1*J_GPIO Pin

GPIO control pin（10Pin ，2*5Pin，2.0mm）

Environment

working temperature：-20℃~60℃；Working humidity：5%~95% Relative humidity, non condensing

BIOS

AMI BIOS，It supports power on, regular power on, and intelligent identification of remote switching equipment

OS

Support Windows 10，Windows 8，Windows 7，Linux etc.
