Size

214mm*150mm*52mm （With Vesa: 235mm*150mm*52mm）

145 *100 *18mm

CPU

Intel® CPU: 1037U、2117U、Gen3rd U series Core i3、i5、i7

Chipsets

Intel 7 series chipsets：HM70、HM76、HM77、QM77

Power

1*DC_IN

Support 12V Voltage；The full load power consumption of the host is about 35W. 12v5a or above power supply is recommended

Ram

Onboard NB-DDR3 1600MHz Ram，2G/4G as option

Graphic

Integrated Intel® HD 4000 Graphic controller, supporting single display,
Dual display replication, double display expansion, and single display under DOS

1*VGA DB15 Port

Resolution: 1920*1200@60HZ

1*HDMI 1.4 Port

Resolution: 1920*1080@60HZ

Ethernet

1*LAN RJ45 Port

Integrated Realtek 8111E Gigabit network card chip, supporting network switch and PXE diskless boot function

1*Mini-PCIE Port

WiFi module that only supports PCIe signal

Storage

1*SATA1 Port

Standard SATA3.0 Hard disk interface, maximum transmission speed 6.0 Gbps

1*SATA2 Port

Standard SATA2.0 Hard disk interface, maximum transmission speed 3.0 Gbps

1*MSATA Port

Support MSATA，Support WIFI/4G/Bluetooth etc.

Audio

Integrated Realtek ALC662 HD Digital audio decoder, 6-channel high fidelity audio controller

1*SPK Port

Support audio output

USB

2*USB3.0 Port

Post standard USB 3.0 interface

6*USB2.0 Port

Post standard USB 2.0 Interface

Switch

1*POWER Button

Switch button, power light

I/O

6*COM

Serial Port，Support standard RS232；Com2 can optionally support RS232/RS422/RS485

1*SIM Card Slot

Support SIM Card，for matching with 3G/4G Module

Environment

working temperature：-20℃~60℃；Working humidity：5%~95% Relative humidity, non condensing

BIOS

AMI BIOS，It supports power on, regular power on, and intelligent identification of remote switching equipment

Watch Dog

Watchdog programming, supporting hardware reset function（256 levels, 0~255 seconds）

OS

Windows 10，Windows 8，Windows 7，Windows XP，LINUX etc.
