Size

160mm*126mm*57mm

145mm*100mm*18mm

CPU

Gen6th

3855U、3955U及Skylake i3-6100U、i5-6200U、i7-6500U etc.

Gen7th

3865U、3965U及Kabylake i3-7100U、i5-7200U、i7-7500U etc.

Chipsets

SOC in CPU

Power

1*DC_IN

DC head Internal diameter is 2.5MM，Support 12V~24V Wide voltage power supply

power consumption：35W, 12v5a or above power supply is recommended

Ram

Onboard NB-DDR4 2133MHz Ram，4G/8G for Options

Graphic

Gen6th

Intel HD Graphics 510/520 Graphic controller
Intel HD Graphics 610/620 Graphic controller

Gen7th

Support single display, double display replication, double display / expansion, and single display under DOS

1*VGA DB15 Port

Max support resolution 1920*1200@60HZ

1*HDMI 1.4 Port

Support 4K resolution 4096/3840*2160@24/30HZ

Ethernet

1*LAN

Rtl8111f gigabit network card chip supports network wake-up and PXE diskless boot functions.

1*Mini-PCIE Port

Support wifi/3g/4g/ Bluetooth, and optionally support msata

Storage

1*SATA1 Port

Standard sata3.0 hard disk interface, with a maximum transmission speed of 6.0 Gbps

1*M.2_SSD

Support M.2 2280 SSD，Support SATA / NVME（PCIE）Protocol optional

Audio

Integrated Realtek ALC662 HD Digital audio decoder, 6-channel high fidelity audio controller

1*AUDIO Port

Support audio output

USB

2*USB3.0 Port

Post standard USB 3.0 interface

6*USB2.0 Port

Post standard USB 2.0 interface

Switch

1*POWER Button

Switch button, power light

I/O

6*COM Port

Serial port, COM1 supports rs232/rs422/rs485 optional

1*SIM Card Slot

Support SIM card, which is required when using 3g/4g

Environment

Working temperature：-20℃~60℃；Working humidity：5%~95% Relative humidity, non condensing

BIOS

AMI BIOS，It supports power on, regular power on, and intelligent identification of remote switching equipment

Watch Dog

Watchdog programming, supporting hardware reset function（256 levels, 0~255 seconds）

OS

Support Windows 10，Windows 8，Windows 7，Linux etc.
